BlackVue Cloud Module

Connect To The Cloud

With 4G LTE, just bring your own data sim.

Real Time Alerts

Receive live notifications via the BlackVue App.

Live View

Log in and remotely view your camera feed.


State of the art dash camera technology meets the cloud, simply BYO compatible Nano SIM Card and experience live viewing, notifications and added storage.

Color/Size/Weight: Black / Length 90 mm x Width 60 mm x Height 10 mm / 110g

LTE Module: Quectel EC25

LTE Supported Band:

  • EC25-A : B2/B4/B12
  • EC25-J: B1/B3/B8/B18/B19/B26
  • EC25-E : B1/B3/B5/B7/B8/B20

LTE Features:

  • Support up to Non-CA CAT. 4 FDD
  • Support 1.4/3/5/10/15/20MHz RF Bandwidth
  • LTE-FDD : Max 150Mbps(DL) / Max 50Mbps(UL)

Transmitting Power: Class 3: 23dBm +/-2dBm @ LTE-FDD Bands

SIM Type: Support Nano SIM Card / 3.0V

Connector Type: Micro USB Type-B Connector with Harness Cable


USB Interface: Compliant with USB 2.0 specification (Slave Only), Reach up to 480Mbps for data transfer rate

LTE Antenna Type: Fixed / Antenna (Main, Diversity)

Power Supply:

  • USB Harness Cable: 3m
  • Typical Supply Voltage: 5.0V / 1A
  • Supply Input Voltage: 3.3V ~ 5.5V / Max. Current: 2A

Power Consumption: Idle Mode: 30mA / Traffic Mode: 620mA @ Max. Power

Temperature Range:

  • Operation Temperature Range: -35°C ~ +75°C
  • Storage Temperature Range: -40°C ~ +85°C

Certifications: CE, UKCA, FCC, ISED, RCM, TELEC, KC, WEEE, RoHS
