BlackVue Battery Packs
KEY FEATURES:
Dedicated Battery Supply
Bypass your vehicles own battery with a dedicated LiFePO4 battery.
Bluetooth on B-130X
Providing direct and immediate dash camera data.
Lithium-Iron Power
Ensuring reliability for extended Parking Mode.
Explore the benefits of using Parking Mode in your car with your BlackVue Dash Camera. Parking mode is enabled by hard wiring your dash camera into your car, giving it power once your car is switched off. You can extend Parking Mode battery life and enhance security by adding a dedicated BlackVue backup battery.
Model Name: Power Magic Battery Pack (B-112)
Capacity: 12.8 V / 3000 mAh / 38.4 W
Product Dimensions: Black / 128 mm (W) x 102 mm (L) x 50 mm (H) / 550 g
Operation Temperature:
- Charging Temperature: 0°C – 45°C
- Discharging Temperature: -20°C – 60°C
- Storage Temperature: -20°C – 60°C
Backup Battery: Type: LiFePo4
Input Power
- MAX: Cigarette lighter plug: 9 V–24 V / 6.5 A
- MIN: 9 V / 9.75 A, MAX: 24 V / 3.65 A
Power Consumption Hour:
- Approx. 12 hours | 12 V / 2.8 kWh power consumption 1CH Dashcam
- Cigarette lighter plug: Approx. 1 hour
Rated Output Voltage:
- When charging from a 12 V cigarette lighter socket:
- 2 USB sockets: each 5 V / 2 A
- Dashcam: 12 V / 1 A
- When charging from a 24 V cigarette lighter socket:
- 2 USB sockets: each 5 V / 2 A
- Dashcam: 24 V / 0.5 A
- When discharging the battery:
- 2 USB sockets: each 5 V / 2 A
- Dashcam: 12.8 V / 1 A
Output Current / Quiescent current: 12.8 V / 20 mA
Power cut-off voltage (based on the input voltage): 14.6 V / 3.5 A
Others: MIN: 5 V / 100 mA
Warranty: 1 year manufacturer’s warranty
Model Name: Power Magic Ultra Battery (B-130X)
Capacity: 12.8 V / 7,500 mAh / 96 Wh
Product Dimensions: Black / 157 mm (W) x 171 mm (L) x 39.5 mm (H) / 1.4 kg
Operation Temperature: 10°C − 60°C
High Temp Cut Off: Approx. 80°C (176°F)
Backup Battery: LiFePo4
Input Power:
- 12V system:
- Cigarette lighter plug: 12 V–17 V / 6.5 A (max)
- Hardwired: 12 V–17 V / 13.5 A (max)
- 24V system:
- Cigarette lighter plug: 23 V–30 V / 3.4 A (max)
- Hardwired: 23 V–30 V / 7.1 A (max)
Power Consumption Hour:
- Cigarette lighter plug: 14.2 V / 5 A
- Hardwired: 14.2 V / 9 A
- Cigarette lighter plug (standard 5 A charging): Approx. 80 mins
- Hardwired (rapid 9 A charging): Approx. 40 mins
- Hardwired (rapid 9 A charging): Approx. 40 mins
- Approx. 25 hours 35 mins (based on a single dashcam that consumes 3 W)
Output current / Quiescent current: Dashcam port: 11 V–14.2 V / 2 A (max)
Others: USB port: 4.75 V–5.25 V / 2 A (max)
